Project Folder Architecture

Folder structure is a design document that cannot go stale. If the layout is right, a new reader can guess where things are. If it is wrong, no amount of README compensates.

This article walks the real tree of the ASL Sign Character project, including the parts that are wrong, because a structure article that only shows the good decisions is not useful.

Sign Character Project/
|-- ARTICLES_SPEC.md               spec for this article series
|-- README.md                      project documentation
|-- my sign character.blend        the character (never written by the pipeline)
|-- my sign character.blend1       Blender's automatic backup
|
|-- data/                          SOURCE data, as downloaded
|   |-- asl-lex/
|   |   |-- signdata.csv           2.0 MB - ASL-LEX 2.0, latin-1 encoded
|   |   `-- signdataKEY.csv        45 KB - column definitions
|   `-- lexicon/                   (empty - leftover)
|
|-- tools/                         build-time scripts, run outside Blender
|   `-- build_lexicon.py           CSV -> runtime JSON
|
|-- blender/                       scripts that run INSIDE Blender
|   |-- facial_morphs.py           generates the 20 facial morphs
|   |-- body_profile.py            fits collision volumes to the mesh
|   |-- export_character.py        non-destructive GLB export
|   `-- preview_morphs.py          renders one face close-up per morph
|
|-- articles/                      this series
|
|-- ASL data/                      3.8 GB of screen recordings (see below)
|
`-- web/                           the Next.js application
    |-- package.json
    |-- next.config.mjs
    |-- tsconfig.json
    |-- app/                       Next.js app router
    |   |-- layout.tsx
    |   |-- page.tsx               UI, state, dev hooks
    |   `-- globals.css
    |-- public/                    static assets, fetched at runtime
    |   |-- character/
    |   |   |-- sign_character.glb    10 MB
    |   |   `-- rig_manifest.json     bones, anchors, collision, morphs
    |   `-- data/
    |       `-- asl_lexicon.json      1.2 MB - 2,719 signs
    |-- src/
    |   |-- asl/                   the animation system (12 modules)
    |   `-- components/
    |       `-- SignStage.tsx      three.js scene, render loop
    `-- test/
        `-- run.ts                 headless checks

The organising question is when does this code run?

• data/: Never (it is data). CSV. No runtime.

• tools/: Build time, once. Python 3. Needs system Python.

• blender/: Build time, once. Python 3.13. Needs Blender's interpreter.

• web/src/: Every frame. TypeScript. Needs a browser.

Those four contexts have nothing in common. They cannot share code, they cannot share dependencies, and they run at completely different frequencies. Splitting them at the top level makes that boundary explicit.

Why tools/ and blender/ are separate despite both being Python: they run in different interpreters. blender/ scripts import bpy, which only exists inside Blender's bundled Python 3.13. tools/build_lexicon.py runs in your system Python and would fail inside Blender's environment for lack of installed packages.

Putting them in one scripts/ folder would mean every file needs a comment explaining which interpreter runs it. The directory name does that job for free.

Why data/ is separate from web/public/data/: this is the important one.

data/asl-lex/signdata.csv          2.0 MB   source, as downloaded
web/public/data/asl_lexicon.json   1.2 MB   generated, shipped to the browser

One is input, the other is output. build_lexicon.py transforms the first into the second. Keeping them apart means you can always tell which files are derived and therefore safe to delete and regenerate.

This was an explicit constraint in the goal prompt:

keeping every file, model, dataset, script, asset, and generated output
inside the existing "Sign Character Project" folder

Left to their own devices, agents and build tools scatter: a dataset into a ~/.cache directory, a model into a global package location, a temp file into /tmp.

The result of enforcing containment is a directory you can copy to another machine and have work. The ASL-LEX CSV is in data/. The exported GLB is in web/public/character/. The built lexicon is in web/public/data/. Nothing lives outside.

The cost: the folder is large, 3.8 GB of it is screen recordings, and 10 MB is the character. Containment trades disk for portability. For a project that runs entirely on one machine, that is the right trade.

This is where the real design work is. Twelve modules in web/src/asl/, and the dependency graph is the point (the animation system itself is documented in Part 6 on building natural ASL animation):

                            types.ts
                               |
        +------------+---------+----------+----------+
        v            v         v          v          v
   handshapes   locations   overrides   gloss    anatomy
        |            |         |                    |
        +------+-----+         |                    |
               v               |                    v
         fingerspell           |                  rig.ts
               |               |                    |
               +-------+-------+--------+-----------+
                       v                v
                  synthesize.ts  <-- player.ts --> face.ts
                       |                |
                       +--------+-------+
                                v
                          diagnostics.ts

Measured from the actual imports:

anatomy.ts       <-
face.ts          <-
types.ts         <-
gloss.ts         <- types
handshapes.ts    <- types
locations.ts     <- types
overrides.ts     <- types
rig.ts           <- anatomy types
fingerspell.ts   <- handshapes locations types
player.ts        <- face handshapes locations rig types
diagnostics.ts   <- anatomy player rig types
synthesize.ts    <- anatomy fingerspell handshapes locations overrides player types

Three things worth reading out of that.

1. 1

   types.ts imports nothing: It is the shared vocabulary: Vec3, Handshape, HandTarget, Pose, Keyframe, NonManual. Everything depends on it and it depends on nothing, so there are no cycles by construction.

2. 2

   gloss.ts depends only on types.ts: The entire English to ASL grammar layer has no knowledge of rigs, rendering, or three.js. That is why it can run headless in Node, and why the test suite can check grammar without a browser.

3. 3

   anatomy.ts and face.ts import nothing at all: They are pure. anatomy.ts holds joint limits and the body collision volume; face.ts holds blink and saccade timing. Both are self-contained models that could be lifted into another project unchanged.

The layering that emerges:

LAYER 0   types                         vocabulary
LAYER 1   anatomy, face                 pure models, no deps
LAYER 2   handshapes, locations,        data + lookup
          overrides, gloss
LAYER 3   rig, fingerspell              rig binding, composed data
LAYER 4   player                        interpolation, runtime state
LAYER 5   synthesize                    orchestration
LAYER 6   diagnostics                   observation

Nothing in a lower layer imports from a higher one. That was not enforced by a linter: it fell out of separating by responsibility, and it is what made bisection possible during debugging. When flicker appeared, I could ask is this synthesis or the solve because those are different files with a one-way dependency.

Note diagnostics.ts sits at the top. The measuring instrument depends on everything and nothing depends on it. That is correct: observation should be removable without affecting behaviour.

synthesize.ts imports from player.ts:

import { handOrientation, samplePose } from './player';

Synthesis producing keyframes should not need the player. But the cleanup passes have to know what the animation will actually look like after interpolation. Checking a hand's angular speed means computing the orientation the way the player will. Duplicating that logic would guarantee drift between what synthesis checks and what the player does.

gloss.ts, synthesize.ts, rig.ts, player.ts, anatomy.ts, diagnostics.ts.

Single words, lowercase, no prefixes. No aslGlossTranslator.ts or ASLSynthesisEngine.ts.

Why: the folder is already asl/. Repeating the domain in every filename is noise. Within a well-named folder, short names read better.

X_head, X_eyes: the X_ prefix marks duplicated meshes in the export's temporary collection:

dup.name = "X_" + src.name

Why: during export, both the original head and the duplicate exist simultaneously. Without a prefix you are one bpy.data.objects["head"] away from modifying the source. The prefix makes the destructive-looking operation obviously safe.

def clean_bone_name(name):
    """DEF-f_index.01.L -> f_index_01_L  (dot-free, three.js friendly)."""

Dots are property-path separators in several toolchains. The rename happens once, at the boundary between Blender and the web.

The face mesh is eyelasshes: the original author's spelling.

FACE_MESH_ROLES = {
    "head": "skin",
    "Plane": "brows",       # the eyebrow strip
    "eyelasshes": "lashes",  # rides the upper lid
    "eyes": "eyeballs",     # rigid spheres, gaze rotation only
}

Why not fix it: renaming a mesh in a file you did not model breaks vertex group references, modifier targets, and anything else pointing at it. The comment carries the meaning; the string matches reality.

Plane is worse: a mesh named after the primitive it started as, which happens to be the eyebrow strip. The role mapping is what makes that legible.

The clearest test of separation is: can you change one thing without touching the others?

• Add an ASL grammar rule: One file. gloss.ts.

• Fix a sign's palm orientation: One file. overrides.ts.

• Change how fingers curl: One file. rig.ts.

• Add a facial morph: One file plus re-export. blender/facial_morphs.py.

• Change interpolation: One file. player.ts.

• Add an artifact detector: One file. diagnostics.ts.

• Change the UI: One file. app/page.tsx.

Each row is one file. That is the payoff.

The counter-example from this project: adding mouth morphemes touched three files, gloss.ts (which sign gets which morpheme), synthesize.ts (what the morpheme does to the face), and test/run.ts (assert they connect).

That is a genuine cross-cutting feature, and it produced a genuine cross-cutting bug: gloss.ts emitted puff, synthesize.ts had no puff entry, and the mouth silently did nothing. The seam between two files is exactly where that class of bug lives.

The fix was not to merge the files: they have different responsibilities, and merging would have made both worse. It was a test that asserts every morpheme one file can emit resolves in the other.

web/
|-- app/           Next.js routing + UI
|-- src/asl/       animation system (framework-independent)
|-- src/components/  three.js scene
|-- public/        static assets
`-- test/          headless checks

Why src/asl/ is not under app/: nothing in it imports React or Next.js. It is plain TypeScript operating on data structures. That is what lets test/run.ts run it under tsx with no browser and no bundler:

npx tsx test/run.ts

The test suite exercises all 2,719 signs, checks every wrist target is reachable, and validates keyframe cleanup, in a couple of seconds, with no DOM.

If the animation system imported from app/, none of that would work. Framework independence is not purity for its own sake; it is what makes the code testable.

Why public/ holds the GLB and lexicon: they are fetched at runtime rather than bundled. A 10 MB GLB in the JavaScript bundle would be absurd. In public/ they are static files the browser can cache independently of the code.

Four real problems, in the tree right now.

ASL data/
|-- Screen Recording 2026-08-01 at 10.33.43 PM.mov
|-- Screen Recording 2026-08-02 at 1.07.13 PM.mov
|-- ... (7 recordings total)
`-- Screenshot 2026-08-02 at 1.27.06 PM.png

Three point eight gigabytes. The entire rest of the project is about 14 MB.

A leftover from an earlier plan where the built lexicon was going to live there before it moved to web/public/data/.

Why it is still there: nobody deletes empty directories. They are invisible in most file listings and cost nothing, until someone puts a file in one, assuming it is the intended location.

Fix: delete it.

No .git directory.

This is the real problem in the list. Everything else is cosmetic. Without git:

• The rejected-fix comments in the code are the only record of what was tried. They are good comments, but they are not a history.

• There is no way to bisect a regression.

• The 3.8 GB of recordings would need a .gitignore before the first commit, which is a reason it has not happened.

What I would do: git init, a .gitignore covering node_modules/, .next/, __pycache__/, ASL data/, and *.blend1, then commit. The .blend at ~50 MB should go in Git LFS or stay out of the repo entirely with a note about where to get it.

A TypeScript incremental build cache sitting in web/. Generated, machine-specific, and would be noise in a repository. It belongs in .gitignore.

Four properties, in rough order of value.

1. 1

   Regenerable artifacts: Every generated file can be rebuilt from a script in the tree. Delete either output and one command brings it back. Nothing generated is precious.

2. 2

   The rig is calibrated, not hard-coded: Bend axes, palm normals, and segment lengths are measured from the rest pose at load time. Re-export the character with different proportions and the solver recalibrates. There is no table of magic numbers to update.

3. 3

   Decisions are recorded where they will be questioned: Rejected fixes live as comments next to the constant someone will want to change. A separate decisions document does not get read at the moment of temptation. A comment does.

4. 4

   The test suite runs without infrastructure: npm test (tsx test/run.ts) with no browser, no server, taking seconds. A test that is slow or needs setup gets skipped. This one exercises the whole synthesis path across every sign in the lexicon and finishes before you look away.

Example rejected-fix comment sitting next to a tunable constant:

/**
 * Slowing BOTH to 1.2 cut flicker (141 -> 112) but let collisions straight
 * back in (head penetration 0 -> 53).
 */
const MAX_ESCAPE_RATE = 14.0;

Mostly yes. Three changes:

• Separate media from data by name, from day one: ASL data/ versus data/ is a naming collision that cost nothing to avoid and now requires a rename.

• Initialise git first, before anything else: The absence of history is the one structural mistake with no cheap fix.

• Consider splitting rig.ts: At 1,363 lines it is the largest file in the project and it holds three distinct responsibilities: rig binding and calibration, IK solving, and collision resolution. They are cohesive (the resolvers need the solver) but the file is at the size where finding things gets slow. Splitting into rig-bind.ts, rig-solve.ts, rig-collide.ts would probably help.

What I would not change: the four-way top-level split by execution context, the framework-independent animation system, and keeping generated artifacts separate from source. Those three carried the project.

1. 1

   Split the top level by when code runs: Not by what language it is in. tools/ and blender/ are both Python but use different interpreters.

2. 2

   Never mix source and generated files: data/ holds the downloaded CSV; web/public/data/ holds the built JSON.

3. 3

   Keep the domain logic framework-independent: src/asl/ imports no React and no Next.js, which is what lets the test suite run headless in seconds.

4. 4

   Let the dependency graph enforce layering: types.ts imports nothing, gloss.ts imports only types, diagnostics.ts sits on top and nothing depends on it.

5. 5

   If two modules must agree on a computation, one imports it from the other: Duplicating a formula guarantees eventual drift.

6. 6

   Add a test at the seam when a feature spans files: That is exactly where the puff bug lived.

7. 7

   Convert naming conventions at the boundary, not throughout: DEF-f_index.01.L becomes f_index_01_L in one function.

8. 8

   Match names you did not choose, including misspellings: Comments carry meaning; strings must match reality.

9. 9

   Record rejected decisions next to the code that invites them: Not in a separate document.

10. 10

    Label what is and is not a pipeline input: Containment without labelling produced a 3.8 GB folder that looks like a data source.

11. 11

    Initialise version control before anything else: It is the one structural mistake here with no cheap retrofit.
